Vacuum Assisted Centrifugal Dry Priming Pumps
Basic Info.
| Model NO. | YP150 |
| Model Number | Yp |
| Structure | Single-Stage Pump |
| Theory | Centrifugal Pump |
| Brand Name | Yonjou |
| Place of Origin | Zhejiang, China (Mainland) |
| Transport Package | Standard Export Plywood Case |
| Specification | standard |
| Trademark | YONJOU |
| Origin | China |
| HS Code | 841311000 |
| Production Capacity | 500 Set/Sets Per Month |
Product Description
Summarize:
The Dewatering Pump, Vacuum Assist Dry Run Self Priming Pump consists of a self-priming centrifugal pump with semi-open impeller and a Simplex separator where air can separate from the liquid and be sucked by a vacuum pump.
The vacuum pump allows the unit to be primed automatically and capable of drawing significant quantities of air, allowing the priming of a wellpoint system and maintaining it under vacuum, or draining an excavation thoroughly under "snore" conditions.
Performance data:
Parameter | YP100 | YP125 | YP150 | YP200 | YP250 | YP300 |
Casing Material | Cast Iron | Cast Iron | Cast Iron | Cast Iron | Cast Iron | Cast Iron |
Impeller Material | SS304 | SS304 | SS304 | SS304 | SS304 | SS304 |
Standard Pump Shaft Material | 2cr13 | 2cr13 | 2cr13 | 2cr13 | 2cr13 | 2cr13 |
Inlet & Outlet Size | 100mm | 125mm | 150mm | 200mm | 250mm | 300mm |
Solids Handling Capability(maximum diameter) | 20mm | 26mm | 76mm | 76mm | 50mm | 65mm |
Maximum Lift | 9.5m | 9.5m | 9.5m | 9.5m | 9.5m | 9.5m |
Maximum Discharge Head | 32m | 34m | 42m | 53m | 60m | 55m |
Maximum Flow | 150m3/h | 200m3/h | 360m3/h | 540m3/h | 1000m3/h | 1800m3/h |
Bearing Type | Ball | Ball | Ball | Ball | Ball | Ball |
Nominal Speed | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 |
Company information:
Zhejiang Yonjou Technology Co., Ltd is one of the leading manufacturers and exporters in the field of industry pumps with manufacturing facilities in mainland China. We are specialized in oil pump, diaphragm pump, diesel engine pump, centrifugal pump, screw pump, chemical pump etc.
